FIxed Athermalized IR Lens 60mm f/1.0
- Model
- GLA6010K
Item specifics
- LWIR Lens
- 60mm f/1.0
- Applications
- Security and Surveillance
Review
Description
- Specifications
- Download file
- FAQ
- Video
- Applications
Specifications
|
HFOV
|
160x120
|
320x240
|
336x256 | 384x288 | 640x480 | 640x512 | 1024x768 |
1280x1024
|
25μm | / | / | / | 9.1° | 15.2° | / | / | / |
|
17μm
|
/
|
/
|
5.5° | 6.2° | 10.4° | 10.4° | 16.5° |
/
|
|
12μm
|
/
|
/
|
3.8° | 4.4° | 7.3° | 7.3° | 11.7° |
14.6°
|
Optical |
|||
|
Focal Length[mm]
|
60
|
||
|
F/#
|
1.0
|
||
Wave Length | 8-12μm | ||
Format | Φ21.8 | ||
Mechanical |
|||
|
Fixed Athermalized
|
||
|
|
||
|
Weight
|
|
||
Environmental |
|||
Sealing | IP67 | ||
Operating Temperature | -40℃ to +60℃ | ||
Storage Temperature | -45℃ to +65℃ | ||
|
External Coating
|
DLC/AR
|
||
Download document
|
file name
|
type |
download
|
||
PDF |
|
|||
FAQ
What are the features of GLA6010K lens?
Support hd movement, a larger focal length and a smaller size，Threaded connection is easy to install on all kinds of equipment, can work in all kinds of harsh environment，The coated lens surface not only receives more radiation but also better protects the lens from wear and tear, thus increasing the lens life.
APPLICATIONS
Airborne
Enhanced Vision
Hand-held Thermal Imaging Devices
Maritime & Naval Surveillance
Security & Surveillance
Thermal Imaging Body Temperature Screening
